Slimline II Ute Tray Platform Kit - By Front Runner

SKU: KRXD001

$1,449
Size:

This kit creates a full size rack that sits above your Ute tray. This Slimline II cargo carrying rack kit contains the Slimline II tray (1255mm x 1358mm), 2 Tracks, and 4 Ute Bed Universal Legs that fit into the Tracks. Drilling is required for installation.

All Front Runner Rack Kits contain installation instructions as well as all the components needed to mount the Slimline II Tray to your vehicle.

All Front Runner Rack Kits contain installation instructions as well as all the components needed to mount the Slimline II Tray to your vehicle. The vehicle specific foot rails have openings for storing compatible gear under the rack such as Front Runner tables.

These Foot Rails contain 1 opening to access a Front Runner under rack mount table (1 smaller prep table or 1 larger camp size table).

All Front Runner Racks are backed by a Limited Lifetime Warranty*

For further information on installation, please see the fitment instructions in the INSTALL tab.
KRLB001T - SLIMLINE II UTE TRAY PLATFORM KIT / 1255MM(W) X 1358MM(L) - BY FRONT RUNNER

Consisting of:

2 x LASS026 - Universal Load Bed Leg 188mm (Pair) - by Front Runner
1 x RRSTD07 - Slimline II Tray - 1255mm(W) X 1358mm(L) - by Front Runner
1 x TRBU001 - Pick-Up Load Bed Tracks / 1000mm(L) - by Front Runner

Material used:

Black epoxy powder-coated T6 aluminium

3CR12 Stainless Steel

Approximate Installed Weight 25kg (54lbs)

The t-slots on the tops and bottoms of the rack tray slats and edge profiles accommodate standard 8mm bolts.

To determine the approximate height from your vehicle’s roof to the top of your Slimline II Roof Rack, add the height of the Slimline II Tray (50mm/ 2") to the height of the Foot, Grab-on Foot or Strap-On Foot listed above.

If your Slimline II Roof Rack kit uses Legs, add the height of the Slimline II Tray (50mm/ 2") to the height of the Legs to determine the height of the rack from your vehicle’s rain gutters.

If your Slimline II Roof Rack kit uses Foot Rails, add the height of the Slimline II Tray (50mm/ 2") to the height of the Foot Rails to determine the height of the rack from the crown (highest point) of the vehicles roof.

Shipping Dimensions:

Width 450mm (18")
Length 1615mm (64")
Height 140mm (6")

Shipping Weight:

Weight 28.7kg (63.1lbs)

KRLB001T - UTE TRAY SLIMLINE II RACK KIT / 1255MM(W) X 1358MM(L) - BY FRONT RUNNER

We offer installation for all products at our Auckland based West Supply Workshop! Simply choose installation during checkout.

If you're gonna give it a crack yourself, here's all the info you need:

View the Slimline II assembly guide right here:

Slimline II Assembly Guide


View the component installation guides here:

Installation Instructions for KRLB001T


Installation Instructions for LASS026


Installation Instructions for TRBU001

FRONT RUNNER'S LIMITED LIFETIME WARRANTY

All Front Runner Racks are backed by their Limited Lifetime Warranty*
